Overview Chinese CE Multi-Purpose Yaweh Front End Loader Backhoe Compact 4 Wheel Backhoe Loader Product Description 1. L
Overview
Basic Info.
Load and Unload Mode Rear Dump
Walking Mode Wheeled
Type Medium-sized Loader
Transport Package 40hq
Specification 8150*2250*3763
Trademark yaweh
Origin China
HS Code 8429510000
Production Capacity 8000 Sets / Year
Product Description

Chinese CE Multi-Purpose Yaweh Front End Loader Backhoe Compact 4 Wheel Backhoe Loader

Product Description
1. Luxury enlarged cabin, luxury seat , Cabin with hydraulic forward tilting function, easy maintenance.2. The top canopy of the cabin can be removed for container delivery.3. Streamline enlarged fuel tank with tilting oil port, easy to refill4.Hydraulic componentes use famous brand,with long working life and stable performance;oversize water tank,high-temperature resistant; 5. Large radiator suitable for very hot area.6. Hydraulic steering system , easy to control.7. Hydraulic walking , with Chinese best torque converter , contiuously variable transmission;Service brake is air over hudraulic discc brake on 4 wheels, with blast pump.8. It have all the functions of 180°wheel excavator and the same wheel loader.9. Excellent operating performance with high working efficiency10. All kinds of attachments are optional,such as snow blade,road sweeper,hydraulic hammer,grapple, pallet fork, to meet different customer's requirement.11.Can equipped with ROPS cabin as optional.
12.Can equipped with Air conditioner,break hammer,4in 1 bucket,6 in 1 bucket,quick hitch and pre-breaking line as optional.Our Advantages

You know what difference about our backhoe loaders? - Our backhoe loaders deliver the power and precise handling you need when operating in areas where using larger equipment is not practical. Because of their relatively small frame size and versatility our backhoe loaders improve construction productivity and lower your machine operating costs.
- Our backhoe loaders were designed as a system, which means every part plays a critical role. It's why we've made it easier to maintain your machine.
- The shape of our buckets improves digging, loading and material retention.

Chinese CE Multi-Purpose Yaweh Front End Loader Backhoe Compact 4 Wheel Backhoe Loader

We Pay More Attention To Details, Details Are Our Quality 1. It has excellent work efficiency and cost performance.
2. The standard bulldozer can level the site and backfill the earth to increase the stability of the machine.
3. Simple, small and flexible, easy to transport, can work in small sites, especially suitable for orchards, such as kiwi, vineyards, oranges, navel oranges, digging trenches, fertilizing, and weeding.
4. It has multiple functions of mining, crushing, removing hooks, drilling, and earthwork, and can quickly replace accessories,greatly improving the utilization rate of the machine.

What are the advantages of our Backhoe Loader? Advantages of our Backhoe Loader: support multi-function operation, fast attachment of accessories, excavation, crushing, trench cleaning, drilling and bulldozing;

Chinese CE Multi-Purpose Yaweh Front End Loader Backhoe Compact 4 Wheel Backhoe Loader

Product Parameters
The Main Performance Parameter of Backhoe Loader ASG388
Overall dimensionsEngine
Dimension(L*W*H)(mm)6150*2350*3763ModelYudong 4105 supercharged
Wheelbase(mm)2200TypeTurbocharged
Wheel track(mm)1850/2200Rated(kw)85
Min.ground clearance(mm)300Rated speed(r/min)2400
Min.turning radius(mm)6580Number of cylinders-bore4-105
Performance ParametersTransmission system
System pressure(Mpa)28TransmissionFixed-axis powershift
Overall weight(kg)8320Number of gearsFront 2 and back 2
Max. speed(km/h)22Torque converterYJ280
Max. climbing capacity(°)35
Excavation parameterAxle
Max. digging depth(mm)4000/5200TypeWheelside reduction bridge
Excavation unloading height(mm)4500/5300Tires
Max. digging radius(mm)5800/7100Specification14-17.5/19.5L-24
Max. lifting height(mm)6060/7200Travel brakeAir top oil caliper disc brake
Hopper capacity(m³)0.3Parking brakeHandbrake
Excavator slewing angle(°)190
Loading parametersOil volume
Max. unloading height(mm)2742Fuel Tank(L)100
Max. unloading distance(mm)1062Hydraulic oil tank(L)100
Loading bucket capacity(mm)1
Other
Drive typeFour-wheel drive
Variable speed formHydraulic variable speed
Manipulation SystemElectromagnetic hydraulic pilot control
Why choose us

Why Choose Us?

QualityYaweh Heavy Industries utilize only quality, proven componentry in the production of our product range.
All yaweh Machinery undergoes rigorous factory testing for both operation and finish prior to delivery.
WarrantyThe premium range of Yaweh products is supported by a no nonsense 12 month / 2000 hour parts warranty. We will replace any warrantable,defective parts free of charge during this period.We utilize the express services of DHL and TNTWorldwide to deliver parts to you FAST!
Installationyaweh can assist you in the preparation and installation of your new equipment.Our factory trained technicians share with you their detailed and extensive knowledge of the equipment.Company Profile

Chinese CE Multi-Purpose Yaweh Front End Loader Backhoe Compact 4 Wheel Backhoe Loader

Certifications

Chinese CE Multi-Purpose Yaweh Front End Loader Backhoe Compact 4 Wheel Backhoe Loader

Packaging & Shipping

Chinese CE Multi-Purpose Yaweh Front End Loader Backhoe Compact 4 Wheel Backhoe Loader

FAQ

Q:What is yaweh warranty?
We sell every machine at a fair price.As our production increases,we are getting much support from the purchase source of raw meterial. We leave the maximum profit to customer.1) Yaweh: an experienced loader manufacturer with over 11 years.2) Yaweh team: customers-focused,you'll get reply within 5 minutes.3)Yaweh: premium quality with reasonable price.4) Yaweh: CE,BV,SGS,ROPS and FOPS,ISO9001:2008 varified.The quality control is not an empty word in YAWEH.Our products are tested and granted CE certificate.
Q: What is Yaweh warranty?
YAWEH has a professional sales and after-service team.We are trying our best to make a good service for every customer.1) Yaweh after-sales: life-long, meantime offer one year and one month warranty.2) Yaweh proposal: order some wearing parts with loader for easy maintenance.
Q:What about Yaweh delivery term?
Yaweh Transport packaging team helps our customer to transport their machine in safe and secure way without any damage. 30-45 days after down payment received.
Q:What about the payment term?
30% deposit, final payment before delivery
