Tracked Skid Steer Loader Mini Skid Steer Loader with Accessories
Basic Info.
Model NO. | SL75 |
Load and Unload Mode | Front Discharge |
Walking Mode | Wheeled |
Type | Small Loader |
Bucket Capacity | 0.5 |
Brand Name | Kaitian |
Diesel Power | 55 Kw |
Machine Weight | 3500 Kg |
Transport Package | 40hq Container |
Specification | 3580x1880x2160mm |
Trademark | KAITIAN |
Origin | China |
Production Capacity | 2000sets/ Year |
Product Description
Tracked Skid Steer Loader Mini Skid Steer Loader With Accessories>> Introduction
Skid steer loader is a kind of wheel type special chassis equipment that makes use of the linear speed difference between the wheels on both sides to realize vehicle steering. It is mainly used in occasions where the operation site is narrow, the ground is uneven and the operation content changes frequently. It is used for wharf loading and unloading, urban streets, houses, barns, livestock houses, airport runways, etc. at the same time, it can also be used as mechanical auxiliary equipment for large-scale engineering construction.
>> Characteristic
>> Since its minimum turning radius is less than half of the same level of articulated loaders, it is especially suitable foroperations in narrow sites such as urban infrastructure, roads or construction sites, workshops, warehouses, docks, ship decks and even cabins.>> Adopting all-wheel drive and no inter-wheel differential is conducive to work on undulating ground.>> Different working devices can be replaced or hooked up at the job site in an instant, generally only a few minutes>> Used for logistics support, site cleaning and project finishing operations of large construction machinery.>> It can be used as a mobile pump station to provide a power source for hydraulic tools such as hand-held hydraulic picks.>> In road protection, it can be directly used for snow removal and cleaning operations. With snow removal and deicingaccessories, the sliding equipment can quickly clear large areas of snow and icing, while benefiting from the mobility of the equipment itself, ensuring Effective large-scale work of related equipment.
The machines use a low-noise,water-cooled diesel engine that adheres toNational Level ll emission standards.The maintenance-free batteries ensure easystart-up and normal operation even in low-temperature environments. | The hydraulic system uses reliable high-performance hydraulic compo-nents, combined with pilot hydraulicand mechanical operation modes,which is light, flexible and reliable. | Luxury cabin with air conditioner, safety bar protecting operator well. The machine features an ergonomically designedoperation panel with a prominent button layout. |
Deepen tire stability, anti-skid andwear-resistant, suitable for various terrains. | Famouns brand hydraulic joystick controller with long service life,which used to provide good rigidity and operation. | The cooler with a larger area in the same class is suit-able for long-term, high-intensity hydraulic work.Good fan heat performance,long service life, safety andenergy saving. |
SL75 | |||
Item | description | Item | description |
Rated operating capacity(kg) | 1050 | Hinge pin height (mm) | 3150 |
Tipping load (kg) | 2100 | Total height (mm) | 2160 |
Bucket capacity(m3) | 0.5 | Length with bucket (mm) | 3580 |
Hydraulic pump flow (L/min) | 75 | Length without bucket(mm) | 2880 |
Engine power (hp) | 75 | Width with bucket (mm) | 1880 |
Weight(kg) | 3500 | Track width (mm) | 1500 |
Max travel speed (km/h) | 12 | Wheelbase (mm) | 1115 |
Grade ability | 20 | Ground clearance (mm) | 205 |
Tire | 12-16.5 | Dumping angle | 40 |
Fuel/hyd oil capacity (L) | 90/90 | Dumping height (mm) | 2450 |
Height at maximum extension | 4070 | Maximum reach (mm) | 700 |
Acting as a good adviser, our well-trained sales groups and professional technical team propose most rational solutions for our valued client as per practical project requirement. >> Select suitable model & matched equipment. >> Strong technical support. Reply clients' questions within 24 hours. |
We have responsible team from raw material to finished products, and guarantee 100% pass rate. >> Design and manufacture products basis of client's special requirement >> Inspect each machine & matched accessories strictly before delivery >> Timely inform client of production progress. |
We're always with you in after-sale service. >> We can arrange related after-sales representatives for debugging and training at worksite when starting up. >> E-mail, call or door-to-door service in later using.
|
Beijing Jincheng Mining Technology Co.,Ltd(JCDRILL) provide users high quality Mining & Drilling solutions,we always focus on the strategic conception of "Survival by quality, Development by credit''. We have specilized in research, development and produce of rock blasting drilling rig, water well drilling rig, diamond core drilling rig, anchor drilling rig, and relative accessories & drilling services. constantly provide professional drilling solutions for all customers with our advanced technology, excellent equipment, strict testing means and good service network,which establish our brand "JCDRILL" a good image of market, now,we products account for 50% of domestic market and have been export to more than 40 countries, and we awarded ISO9001: 2000 in November, 2002. With excellent technology and solid market service capabilities, we have both a sound marketing system and excellent service support system, which help us win confidence of customers both at home and abroad,we can provide drilling rig users with high quality professional air compressor solution and relative after-sales service also. |
>> FAQ
Q: Are you original manufacturer? | Q: Which payment terms are available to us? | Q: Which Incoterms 2010 terms can we work? |
A: Yes, we JCDRILL is a official leading manufacture in drilling machinery in China and we have the whole series products you need. | A: T/T term or L/C term. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment. On L/C term, a 100% irrevocable L/C without "soft clauses" can be accepted. | A: We JCDRILL are a professional and international company, accept all Incoterms 2010 terms, normally we work on FOB, CIF, CFR, CIP. |
Q: How long will the delivery time take? | Q: How about after sales service? | Q:Spare Parts When You Need Them |
A: Normally products will take about 3-15 days to produce the ordered machines. Most of the time, we can have an immediate delivery of our regular machines in 15 days. | A: 365×24 Year-round Service We are committed to year-round 24-hour service even during holidays, in line with our policy of always providing "a response within 15 minutes and job completion within 24 hours." | A:We have spare parts centers across continents that stock specialist spare parts. We promise that spare parts will be delivered within 72 hours or no more than one week. |
